Mid-Powered LED UV Curing Chamber with Rotating Tray (285mm L x 285mm W x 130mm H)

The Mid-Powered LED UV Curing Chamber with a Rotating Tray has a curing area of 250x250nm at the top and 250x60nm at the sides. Available wavelengths are 365nm, 385nm, 395nm and 405nm rapidly and effectively cure most materials, which range from UV glues, inks, and varnishes to paints. This curing system requires no warm-up time and remains cool, protecting heat-sensitive materials and saving you time and money.

The system consists of an oven, UV LED irradiation head, the corresponding connecting wires and a rotary tray that allows a full 3D curing capability with two irradiating points, one on top and one on the side, providing comprehensive coverage for curing, making the process more efficient. The irradiation head is comprised of high-quality UV LEDs. Equipped with a water cooling system, ensuring optimal performance during prolonged use. Also, this chamber supports external signal input and trigger.

 Features:

• Available in 365/385/395/405nm wavelengths are suitable for curing most UV glues, adapting to the job at hand
• Rotary tray helps get more effective results in the same amount of time
• Cold light source makes it suitable for any heat-sensitive material
• Ready for immediate use, maximum light intensity can be reached in an instant
• Easy to control and power saving
• Forced air cooling ensures the system correctly works for prolonged periods
• Mercury-free and ozone-free
• 9.999-second timer


Specifications:

365nm

• Curing area
• Top: 250X250mm - Side: 250X60mm
• Wavelength: 365nm*
• Intensity: 600mW/cm²
• Recommended exposure height: 70-130mm
• Dimension: L553*W403*H393mm
• Curing cavity size:  L285*W285*H130mm
• Input voltage:  120VAC 60Hz

395nm

• Curing area
• Top: 250X250mm - Side: 250X60mm
• Wavelength: 395nm*
• Intensity: 1200mW/cm²
• Recommended exposure height: 70-130mm
• Dimension: L553*W403*H393mm
• Curing cavity size:  L285*W285*H130mm
• Input voltage:  120VAC 60Hz

* Current available specifications apply only to the 365/395nm option

Technical Drawing in Millimeters:

Technical Drawing in Inches:

Product Video:

*The video below doesn't correspond exactly to this product, but rather to a similar one to demonstrate its functionality

If you require higher irradiation, please let us know so that we can offer you our water cooling systems, or if you have questions about this or any of our UV Chambers & Ovens, please feel free to call us at 1(800) 977-7292 or email us at sales@cureuv.com. We would love to help you find the ideal UV solution for your application.
