LED Spot Cure - 3/4/6/8/20/12/15/20mm Light Guide
LED Spot Cure - 3/4/6/8/20/12/15/20mm Light Guide
Regular price
$349.99 USD
Regular price
Sale price
$349.99 USD
Unit price
per
SKU:303179-365
Couldn't load pickup availability
Replacement or additional 10mm Light Guide for our LED Spot Cure System
This guide can be added to your LED Spot Cure System and used for curing larger areas.
Technical Specifications:
- Size of Controller: 185mm L x 100mm W x 125mm H
-
Terminal I/O:
- Input: Pedal Switch & Serial RS-232 Communication Signal
- Output: Serial RS-232 Communication Signal
- Cooling Method: Air Cooling
-
Power Supply Voltage: AC100~240V±10% (50/60HZ)
- Power: 20W
- LED Hour Rating: 25,000 hours
- Cable Length: 2 or 5 Meters
-
Operating Temperature & Humidity:
- Operating Temperature: 14° F to 122° F
- Ambient Humidity: 25% - 85%RH
- Ambient Temperature: -15℃ ～+ 50℃
-
Dimensions:
- Length: 68mm
- Outer diameter: 12mm
- Available in: 365nm, 395nm, & 405nm
This is a medium-sized light guide we offer and can deliver 1200 mW/cm2 at a 30mm distance.
Technical Data Sheet:
If you have any questions or are just unsure about anything give us a call at (561) 243-8442 or email us at sales@cureuv.com and we will gladly help you out.
Also Known As:
Also Known As:
Technical Data for LED Spot Cure
| Spot Diameter | 3mm | 4mm | 6mm | 8mm | 10mm | 12mm | 15mm | 20mm |
|---|---|---|---|---|---|---|---|---|
| Irradiation Distance | 10mm | 15mm | 15mm | 20mm | 20mm | 20mm | 20mm | 25mm |
| 365nm Light Intensity | 10,000 mW/cm2 | 8,200 mW/cm2 |
7,200 mW/cm2 |
3,900 mW/cm2 |
3,700 mW/cm2 |
2,700 mW/cm2 |
1,800 mW/cm2 |
800 mW/cm2 |
| 385nm Light Intensity | 10,000 mW/cm2 | 7,200 mW/cm2 |
6,200 mW/cm2 |
3,400 mW/cm2 |
3,300 mW/cm2 |
2,500 mW/cm2 |
2,200 mW/cm2 |
1,200 mW/cm2 |
| 395nm Light Intensity | 14,000 mW/cm2 | 11,500 mW/cm2 |
10,500 mW/cm2 |
5,800 mW/cm2 |
5,500 mW/cm2 |
3,600 mW/cm2 |
2,100 mW/cm2 |
1,000 mW/cm2 |
| 405nm Light Intensity | 15,000 mW/cm2 | 11,000 mW/cm2 |
10,000 mW/cm2 |
5,500 mW/cm2 |
5,200 mW/cm2 |
2,900 mW/cm2 |
1,900 mW/cm2 |
1,000 mW/cm2 |
