The Ster-L-Ray 05-1119-R UV Replacement Germicidal Light is a 8.35 inches lamp bulb has four pin on one end base and an estimated lifespan of 10,000 hours. We recommend that you replace the bulb every year for better working of your UV system.
When water passes through the UV water treatment system, the microorganisms present in water are exposed to the light and their genetics is disrupted, thus inhibiting their ability to reproduce. This method destroys 99.9% harmful organisms in the water and does not alter the pH, taste or chemistry of water in the process. This method is a better alternative to adding chemicals and their byproducts in water. This system provides protection against water contaminants such as yeast, cyst, bacteria, virus and protozoa.
The germicidal water treatment bulb comes with a shatterproof coating that protects the lamp during damage. The coating also keeps the lamp glass from falling into the unit. This results in easy disposal of glass if it shatters and renders it easy to operate the system. The UV lamp starts instantly and makes use of a coil filament that operates hot. The UV lamp is managed by the life of electrodes and works well for the following applications that require UVC intensity:
Well water
Drinking water
Surface water
Municipal water
Wastewater
Food service/processing
Beverage service/processing
Hospitals
Aquaculture
Pools, Spas and Water Features
Chemicals
Oil, Gas and Power
Pulp, paper and wood
Electronics
Cosmetics
Pharmaceuticals
Hotels
Water bottlers
Laboratories
Marine and more
Technical Specification
Total Length: 8.35 inches (212mm)
Arc Length: 5.51 inches (140mm)
Lamp Quartz Diameter: 15mm
Operating Current: 425mA
Lamp Voltage: 30V
Lamp Wattage: 10 Watts
Peak UV Output: 253.7nm
Glass Type: Non Ozone
Base Style: 4 Pins on one end
Base Material: Ceramic
Rated Life: Up to 9,000 hours
Note: CureUV.com stocks generic products that are 100% compatible with the original equipment.
